ceiling recessed luminaire PANEL FLAT 85 R SCCT DIM C round, CCT Switch, dimmable IP44, black dimmable

nobilé



Are you a retailer or business customer (commercial/freelancer)? Secure special B2B prices now.

High-Quality LED Recessed Panel with Variable Light Color

The LED recessed panel FLAT 85 R SCCT DIM C from nobilé impresses with its versatile application possibilities and high-quality workmanship. With a diameter of 8.5 cm and an installation depth of only 2.5 cm, it fits perfectly into shallow hollow ceilings. The integrated light color can be flexibly adjusted between warm white (3000K), neutral white (4000K), and cool white (5700K), enabling individual lighting scenarios. The stepless dimming function via phase-cut dimming allows comfortable brightness adjustment to suit the respective ambiance.

Energy-Efficient and Durable Lighting Solution

With a power consumption of only 5 watts and a luminous flux of 430 lumens, this LED panel offers an excellent light output of 86 lm/W. Thanks to a long lifespan of up to 75,000 hours, the product is particularly durable and reliable. The color rendering index of over 80 Ra guarantees natural and brilliant color reproduction, which makes everyday life pleasant and optimally illuminates the surroundings.

Robust Design and Thoughtful Technology

The housing of the recessed panel is made of painted aluminum, which is not only stable but also visually appealing. The light distributor and diffuser made of non-yellowing polymethyl methacrylate (PMMA) ensure even and wide light distribution with a beam angle of 120°. The protection rating IP44 guarantees that the panel is protected against splashing water and dust, ensuring high safety and longevity. Installation is significantly simplified by the included clip springs and the connection box with through-wiring.

Flexible Use Thanks to Extensive Accessories

The LED panel is delivered including a dimmable driver, a connection box with terminals for L, N, and PE, as well as clip springs, allowing for quick and secure installation. The lighting solution is available in various sizes and colors, making it easy to adapt optimally to different room concepts. The possibility of through-wiring also simplifies the connection of multiple luminaires in series and makes the system particularly flexible.

Optimal Light Quality for Diverse Applications

The broad and diffuse light output of the panel creates a pleasant atmosphere with uniform illumination. Thanks to a color consistency of 4 SDCM and a color rendering grade of 1B, the product is ideal for use in areas where natural color rendering is important. Combining modern LED technology, ease of use, and robust design, the FLAT 85 R SCCT DIM C represents an efficient and durable lighting solution that impresses both functionally and aesthetically.

Colour:
black
Glass color:
opal
Dimension:
Ø∕ H: 8,5∕ 2,2 cm
Material:
aluminium
polymethylmethacrylat (PMMA)
lacquered
Weight:
0,156 kg
Product type:
ceiling recessed luminaire
Operating voltage:
220-240 V~
Dimmable:
yes
Dimmability:
trailing edge
Power frequency:
50-60 Hz
Power consumption:
5 W
Emitting angle:
120 °
Voltage:
Clamp
Light colour:
warm white to cool white
Beam direction:
down
Light flux:
430 lm
Light yield:
86 lm/W
Colour temperature:
3000/4000/5700 K
Average life span of a bulb in hours:
75000 h
Colour rendering index:
>80 Ra
1B
IK-Rating:
IK00 no impact resistance
Fitting depth:
2,5 cm
Fitting opening circle :
7 cm
Length of connection lead:
45 cm
Protection class:
2
IP-protection class:
IP44
Accessories:
connection box - included in delivery
clip springs - included in delivery
through wiring - included in delivery
light colour switch - included in delivery
driver - included in delivery
dimmer - not included in delivery
Energy consumption:
5 kWh/1.000 h
Article number:
NO-1500851845
Purchasing quantity:
1 piece
Brand:
nobilé
Manufacturer:
nobilé
