light strip system FAST FIX LINEAR SYSTEM S MODULE DALI controllable IP40, white dimmable

ISOLED



Are you a retailer or business customer (commercial/freelancer)? Secure special B2B prices now.

Efficient FastFix LED Linear System S Module for Indoor Use

The FastFix LED Linear System S Module is a high-quality lighting system specifically designed for indoor use. With a power range of 25-75W and a neutral white light color, it provides excellent lighting for various applications.

Versatile Applications and Practical Accessories

The linear system comes with a variety of accessories, including a cover and a driver, which are included in the package. With a size of 150cm and a beam angle of 25°, it offers uniform light distribution and can be used for both surface-mounted and system-mounted installations.

Integrated DALI Dimmability for Individual Light Control

Thanks to the integrated DALI dimmability, the brightness of the linear system can be adjusted as needed. This allows for individual light control and creates a pleasant atmosphere in any room.

Energy Efficient and Long-lasting

With an energy efficiency class of C and an energy consumption of 25-75kWh/1,000h, the LED linear system is not only environmentally friendly but also cost-efficient to operate. The average lamp lifespan of 36,000 hours also ensures long-term use.

Reliable ISOLED Brand and High-Quality Construction

The FastFix LED Linear System comes from the renowned brand ISOLED and impresses with its high-quality construction. With a color rendering index of >80Ra and a color rendering level of 1B, it provides natural and clear lighting in any room.

Article number:
ISO-115241
Purchasing quantity:
1 piece
Brand:
ISOLED
Energy efficiency category:
C
EPREL No:
824414
Product type:
light strip system
Energy consumption:
25-75 kWh/1.000 h
Manufacturer:
ISOLED
Operating voltage:
180-265 V~
Dimmable:
yes
Dimmability:
DALI
Lamp shape:
square
Power frequency:
50/60 Hz
Power consumption:
25-75 W
Emitting angle:
25 °
Bulbs in delivery:
yes
LED can be replaced :
no
Bulb type:
LED
Number of bulbs:
33
Light colour:
neutral white
Light emission:
direct
Light flux:
10600 lm
Nominal current:
416-283 mA
Colour temperature:
5000 K
Average life span of a bulb in hours:
36000 h
Colour rendering index:
>80 Ra
1B
Colour:
white
Material:
steel
plastic
Dimension:
L∕ W∕ D: 144∕ 6,5∕ 2,9 cm
Wire/connection lead diameter:
2,5 ² mm
Plug type:
plug
Mounting:
surfaced mounting
system based mounting
mounting accessories required
Field of application:
ceiling
Protection class:
1
IP-protection class:
IP40
Application area:
only suitable for indoor use
Additional information:
Transformer power: 21 VA
Accessories:
control gear incl
cover incl
bar recording excl
control excl
switch excl
mounting accessories excl
ambient temperature:
0 ... +40 °C
