light strip system FAST FIX LINEAR SYSTEM S MODULE DALI controllable IP40, white dimmable

ISOLED



Are you a retailer or business customer (commercial/freelancer)? Secure special B2B prices now.

Efficient Lighting System

The FastFix LED Linear System S Module from ISOLED is a high-quality lighting system that can be used in offices and other indoor spaces. With a power range of 25-75W and a neutral white light color, it provides pleasant lighting with a luminous flux of 10600lm.

Flexible Adaptation Options

Thanks to DALI dimming capability, the brightness of the linear system can be adjusted as needed. Additionally, the product is equipped with various accessories such as covers and operating devices that enable easy assembly and installation.

Durable and Energy-Efficient

The integrated LEDs have an average lamp lifespan of 36000 hours and an energy consumption of 25-75 kWh/1,000h. This makes the linear system not only durable but also energy-efficient and environmentally friendly.

Safety and Quality

The linear system has a protection class of 1 and an IP protection rating of IP40, ensuring safe use in various indoor spaces. Additionally, it meets the high quality standards of the ISOLED brand.

Easy Installation and Versatile Application

The FastFix LED Linear System S Module can be easily assembled and combined with other systems. With a size of 144 x 6.5 x 2.9 cm and a square design, it fits perfectly in various spaces and ensures optimal light distribution. Perfect for use in ceiling installations and other indoor areas.

Article number:
ISO-115240
Purchasing quantity:
1 piece
Brand:
ISOLED
Energy efficiency category:
C
EPREL No:
824413
Product type:
light strip system
Energy consumption:
25-75 kWh/1.000 h
Manufacturer:
ISOLED
Operating voltage:
180-265 V~
Dimmable:
yes
Dimmability:
DALI
Lamp shape:
square
Power frequency:
50/60 Hz
Power consumption:
25-75 W
Emitting angle:
25+25 °
Bulbs in delivery:
yes
LED can be replaced :
no
Bulb type:
LED
Number of bulbs:
33
Light colour:
neutral white
Light emission:
direct
Light flux:
10600 lm
Nominal current:
416-283 mA
Colour temperature:
5000 K
Average life span of a bulb in hours:
36000 h
Colour rendering index:
>80 Ra
1B
Colour:
white
Material:
steel
plastic
Dimension:
L∕ W∕ D: 144∕ 6,5∕ 2,9 cm
Wire/connection lead diameter:
2,5 ² mm
Plug type:
plug
Mounting:
mounting accessories required
system based mounting
surfaced mounting
Field of application:
ceiling
Protection class:
1
IP-protection class:
IP40
Application area:
only suitable for indoor use
Additional information:
Transformer power: 21 VA
Accessories:
control gear incl
cover incl
bar recording excl
control excl
switch excl
mounting accessories excl
ambient temperature:
0 ... +40 °C
