LED Wall luminaire QUAD 2 XL, square, 8,6W, COB LED, 3000K, 110°, white

SLV



Are you a retailer or business customer (commercial/freelancer)? Secure special B2B prices now.

SLV LED Wall luminaire QUAD 2 XL, square, 8,6W, COB LED, 3000K, 110°, white

Elegant and Modern Design

The QUAD UP/DOWN 15 WL LED wall light impresses with its flat, minimalist, and angular design. Made from high-quality aluminum and glass, it blends harmoniously into various environments. With a compact size of 5.3 x 15 x 10.2 cm, it offers a discreet yet stylish lighting solution. The white color emphasizes the modern look of the fixture, making it ideal for decorative accent lighting on walls.

Powerful and Efficient LED Lighting

Equipped with two fixed COB LEDs, the fixture provides a warm light color of 3000 Kelvin, creating a pleasant and inviting atmosphere. With a total power consumption of 8.6 watts, it produces a luminous flux of 580 lumens with a wide beam angle of 110 degrees upwards and downwards. The LEDs are permanently integrated and cannot be replaced, ensuring a long lifespan of up to 30,000 hours.

Reliable Protection and Durable Materials

The QUAD UP/DOWN 15 WL features an IP44 rating, providing reliable protection against splashing water and dust. Additionally, the IK02 impact protection class safeguards against minor impacts such as hail or vandalism, ensuring high durability. The combination of aluminum and glass makes the fixture robust and long-lasting, allowing it to operate reliably even under changing temperatures from -20 to +40 degrees Celsius.

Easy Installation and Versatile Applications

Designed for wall mounting, the fixture comes with an integrated driver that converts an operating voltage of 100-277 volts AC into a constant DC current of 350 mA. The power connection is made easily via a terminal block, enabling straightforward installation. The wall light is ideal as a spotlight, accent light, or decorative lighting for façades, balconies, pergolas, corridors, and hallways.

High Light Quality and Energy Efficiency

With a color rendering index (CRI) of over 80 Ra, the fixture ensures natural color reproduction and pleasant warm white light. Its energy efficiency is excellent with a consumption of 9 kWh per 1000 hours, making it both environmentally friendly and cost-effective. The SLV brand wall light combines modern design with technical quality and is part of a minimalist series that offers additional matching models for a harmonious lighting concept.

Colour:
white
Glass color:
transparent
Dimension:
W∕ H∕ D: 5,3∕ 15∕ 10,2 cm
Material:
aluminium
glass
Weight:
1,019 kg
Product type:
Wandleuchte
luminary type:
Wall luminaire
Lamptype:
LED
Bulbs in delivery:
yes
Accessories:
driver - included in delivery
Field of application:
wall
Operating voltage:
100-277 V~
Dimmable:
no
Power frequency:
50/60 Hz
Power consumption:
8,6 W
Emitting angle:
110 °
LED can be replaced :
no
Lamps/bulbs:
2x COB LED, 8,6W
Voltage:
Clamp
Light colour:
warm white
Beam direction:
up / down
Light flux:
580 lm
Colour temperature:
3000 K
Average life span of a bulb in hours:
30000 h
Colour rendering index:
>80 Ra
1B
IK-Rating:
IK02 up to 0.20 Joule
Protection class:
1
IP-protection class:
IP44
Additional information:
ta 40°
The luminaire includes built-in LED lamps. The lamps can not be replaced.
Notice for the end user: The light source of this luminaire may only be replaced by the manufacturer or by a service technician appointed by him.
Light emission bidirectional
Lighting effect up and down
Mounting surface on the narrow side (vertical)
We will be pleased to send you a light distribution curve for the respective product on request.
Follower for:
232471
ambient temperature:
-20 ... +40 °C
Energy efficiency category:
F
EPREL No:
916530
Energy consumption:
9 kWh/1.000 h
Article number:
232441
Purchasing quantity:
1 piece
Brand:
SLV
Manufacturer:
SLV
