ceiling luminaire PANEL C 1200/300 DALI DALI controllable, CCT Switch, UGR < 19 IP54 / IP20, dimmable

SLV



Are you a retailer or business customer (commercial/freelancer)? Secure special B2B prices now.

Efficient LED Panel for Standard Grid Ceilings

The LED recessed ceiling light PANEL C 1200 DALI is an efficient panel specifically designed for installation in standard grid ceilings. With a size of 119.5 x 29.5 cm, it fits perfectly into common ceiling constructions and provides uniform illumination of the room.

Steplessly Dimmable Version with DALI Technology

Thanks to DALI technology, this ceiling light is switchable and steplessly dimmable. This makes it ideal for modern building automation systems that require flexible light control. With an external switch on the connecting cable, the light color can be set between warm white (3000K) and neutral white (4000K).

Glare-free Light with High Color Rendering

The LED recessed ceiling light PANEL C 1200 DALI offers good color rendering with a color rendering index of 80-89Ra. This ensures colors are accurately represented, which is particularly important in work environments. Additionally, the luminaire is glare-free according to UGR <19 and therefore ideal for screen workstations.

IP54 Protection against Splash Water and Dust

This ceiling light has a room-side IP54 protection, which protects it against splash water and dust. This makes it perfect for use in rooms with increased humidity or dust exposure. On the rear side, the luminaire offers IP40 basic protection.

Easy Installation and Versatile Application Possibilities

The LED recessed ceiling light PANEL C 1200 DALI is easy to install and has integrated through-wiring, making installation time-saving. With an optional pendant set, the luminaire can also be used as a pendant light. Furthermore, it is ENEC certified and meets the highest quality standards.

Glass color:
white matt
Dimension:
L∕ W∕ H: 119,5∕ 29,5∕ 2,8 cm
Material:
aluminium
Weight:
1,85 kg
Product type:
Deckenleuchte
Lamp shape:
square
Application area:
suitable for indoor use
Field of application:
ceiling
Operating voltage:
220-240 V~
Dimmable:
yes
Dimmability:
DALI,push dimmer
Power frequency:
50/60 Hz
Power consumption:
34 W
Emitting angle:
90 °
Light colour:
warm white / neutral white (in steps)
Light emission:
diffuse
Beam direction:
down
Light flux:
4550 / 4650 lm
Light yield:
133 lm/W
Colour temperature:
3000 / 4000 K
Average life span of a bulb in hours:
70000 h
Colour rendering index:
80-89 Ra
UGR:
< 19
Colour rendering index:
1B
IK-Rating:
IK02 up to 0.20 Joule
Fitting depth:
8.00 cm
Fitting opening square/rectangular width:
117 cm
Fitting opening square/rectangular length:
27 cm
Mounting:
recessed mounting
surfaced mounting
mounting accessories required
Protection class:
2
IP-protection class:
IP54 / IP20
Product ENEC tested:
yes
Follower for:
1003049
Accessories:
control gear included
light colour switch included
mounting springs excluded
pendulum set excluded
ambient temperature:
-20 ... +45 °C
Energy efficiency category:
C
EPREL No:
2166697
Energy consumption:
34 kWh/1.000 h
Article number:
1008607
Purchasing quantity:
1 piece
Brand:
SLV
Manufacturer:
SLV
Manufacturer information
SLV GmbH, Daimlerstraße 21-23, 52531, Übach-Palenberg, Germany, info@slv.de
