SLVtec 2025

SLVtec® 2025 SLV TECHNICAL LIGHTING CATALOGUE

STAY WELL-INFORMED Scan the QR code and stay up to date. Visit us at www.Licht.ch

OUTDOOR PANEL 26 INDOOR EDITORIAL EASYLIGHT 06 PAVANNO 34 TECHNOLOGY THAT MAKES THE DIFFERENCE 06 TRACKSPOT 38 RETRO 16 BULKHEAD 88 FLOODLIGHT 92 EASY TO INSTALL EFFICIENT MULTIFUNCTIONAL BATTEN 64 WATERPROOF 70 UNIVERSAL DOWNLIGHT 56 HIGHBAY 82 DOWNLIGHT 48 SURFACE 60

TECHNOLOGY THAT MAKES THE DIFFERENCE As a reliable partner for electrical installers and the trade, we are constantly developing our product range – practical, future-oriented and with a clear focus on your day-to-day challenges. With SLVtec® we have created an independent brand dedicated entirely to the development of technical, functional and energy-e˜cient lighting solutions. SLVtec® stands for uncompromising quality, innovative product features, high availability as well as quick and easy installation. Whether new build, modernisation or special application: with SLVtec® you can master any project confidently and e˜ciently. FOLLOW THE BLUE STAR – THE NEW SLVtec® PRODUCT WORLD VALUE Reliable essentials for cost-e˜cient projects. CORE The perfect balance between price and performance. PERFORMANCE High-performance lighting for demanding projects. THREE PERFORMANCE CLASSES. COUNTLESS POSSIBILITIES. ONE ANSWER: SLVtec®. Whether you are looking for cost-e˜cient basic lighting, the ideal balance between price and performance or sophisticated lighting solutions: SLVtec® has the right answer for you. All our products combine innovative technology, e˜cient light output and versatile applications for professionals who rely on function and quality every day. 4

5 EASY TO INSTALL, EFFICIENT AND MULTIFUNCTIONAL The e˜ciency of modern technology is evident in the details. Our products not only oŸer excellent lighting quality, but also sophisticated features that make your daily work easier. Easy to install: Intelligent mounting systems, tool-free cabling and innovative quick-release connectors make installation quick and easy, saving time and eŸort. Outstanding energy e ciency: The majority of our products achieve a luminous e˜ciency of more than 120 lm/W. Multifunctionality: With Multi-Colour and Multi-Lumen options, our lighting solutions can be tailored to suit your needs and are flexible to use. CUSTOMISED LIGHTING SOLUTIONS TO ORDER In addition to our widely available stock programme, we also oŸer selected products designed specifically for specific projects. These items are available to order only – perfect for custom lighting designs and bespoke applications. NO CHALLENGE IS TOO GREAT – SLVtec® PROVIDES THE SOLUTION Standard or custom: discover our new portfolio and follow the blue star into a world of innovative technical lighting solutions. Your next project starts here – contact us!

EASYLIGHT COMBINE accessories for diŸerent types of mounting: surface-mounted, cable or chain suspension

C0-C180 3.500 K | 5.000 K C0-C180 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K DA30 WB Oval MB NB 3.500 K | 5.000 K C0-C180 C0-C180 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K DA30 WB Oval MB NB 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K C0-C180 C0-C180 DA30 WB Oval MB NB 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K C0-C180 C0-C180 DA30 WB Oval MB NB 3.500 K | 5.000 K C0-C180 C0-C180 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K DA30 WB Oval MB NB EASYLIGHT PRODUCT ADVANTAGES High energy savings thanks to an e ciency of up to 200 lm/W Service life up to 100,000 hours in five diŸerent beam angles. Other beam angles are available on request EASY TO INSTALL thanks to tool-free assembly Flexibly adjustable thanks to Multi-Lumen and Multi-Colour DALI dimmable and DC-capable Wide light distribution for open areas such as supermarkets, logistics areas and showrooms. Ideal for uniform ambient lighting. Asymmetrical, laterally directed light distribution for targeted illumination of wall surfaces, shelves or presentation zones – ideal for supermarkets or display areas. Balanced light distribution for production areas and workshops where uniform and e˜cient illumination over a medium width is required. Focused light distribution for targeted illumination of high aisles or storage areas with narrow geometries – particularly eŸective at great heights. Elongated light distribution for corridors, hallways and busy areas – optimised for linear room geometries with uniform light distribution. Other beam angles are available on request BEAM ANGLE up to 200 lm/W 7

EASYLIGHT E˜cient. Flexible. Systematic. From industrial halls to supermarkets and logistics centres: EASYLIGHT is the high performance LED continuous-row lighting system for applications where flexibility, e˜ciency and reliability are required. With an impressive e˜ciency of up to 200 lm/W, EASYLIGHT provides energy- and cost e˜cient lighting. Thanks to the innovative quick-fit system, EASYLIGHT can be installed in next to no time, significantly reducing your project times. The sophisticated design fits seamlessly into a wide range of applications. And with a service life of up to 100,000 hours, EASYLIGHT not only reduces maintenance costs, but also your operating costs in the long term. EASYLIGHT AT A GLANCE Up to 200 lm/W – particularly energy-e˜cient Tool-free assembly – save time and eŸort Power and CCT switch – adjustable system output and light colour All variants are DC-capable – controllable and future-proof Various beam angles, lengths and mounting types – can be flexibly combined Seamless connection – continuous light line Quick, tool-free installation – electrical and mechanical connection of modules and lighting units in a single step. Chain or cable suspension is equally quick and tool-free, for flexible adaptation to a wide range of building situations. EASY TO INSTALL 8

Direct ceiling installation, cable or chain suspension possible Robust housing: IP40, IK06 Housing colour similar to RAL 9016, other RAL colours on request Empty panel with cover and cabling: for consistent aesthetics High-output lighting technology with five diŸerent beam angles Luminous flux and light colour can be switched directly on the rear of the light Phase selector switch (L1/L2/L3) on the rear of the light

IP40 IK06 INDOOR EASYLIGHT *S = in stock O = to order EASYLIGHT Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature EASYLIGHT 1500 135 835/840/850 WB WH ML 75 W 220-240 V 13.000 lm 175 lm/W 3.500 K 14.500 lm 195 lm/W 4.000 K 14.200 lm 190 lm/W 5.000 K EASYLIGHT 1500 135 835/840/850 NB WH ML 75 W 220-240 V 13.000 lm 175 lm/W 3.500 K 14.500 lm 195 lm/W 4.000 K 14.200 lm 190 lm/W 5.000 K EASYLIGHT 1500 135 835/840/850 MB WH ML 75 W 220-240 V 13.000 lm 175 lm/W 3.500 K 14.500 lm 195 lm/W 4.000 K 14.200 lm 190 lm/W 5.000 K EASYLIGHT 1500 135 835/840/850 OVAL WH ML 75 W 220-240 V 13.000 lm 175 lm/W 3.500 K 14.500 lm 195 lm/W 4.000 K 14.200 lm 190 lm/W 5.000 K EASYLIGHT 1500 135 835/840/850 DA30 WH ML 75 W 220-240 V 13.000 lm 175 lm/W 3.500 K 14.500 lm 195 lm/W 4.000 K 14.200 lm 190 lm/W 5.000 K EASYLIGHT 1500 135 835/840/850 WB ML DALI2 75 W 220-240 V 12.500 lm 170 lm/W 3.500 K 14.000 lm 190 lm/W 4.000 K 13.500 lm 185 lm/W 5.000 K EASYLIGHT 1500 135 835/840/850 NB ML DALI2 75 W 220-240 V 12.500 lm 170 lm/W 3.500 K 14.000 lm 190 lm/W 4.000 K 13.500 lm 185 lm/W 5.000 K EASYLIGHT 1500 135 835/840/850 MB ML DALI2 75 W 220-240 V 12.500 lm 170 lm/W 3.500 K 14.000 lm 190 lm/W 4.000 K 13.500 lm 185 lm/W 5.000 K EASYLIGHT 1500 135 835/840/850 OVAL ML DALI2 75 W 220-240 V 12.500 lm 170 lm/W 3.500 K 14.000 lm 190 lm/W 4.000 K 13.500 lm 185 lm/W 5.000 K EASYLIGHT 1500 135 835/840/850 DA30 ML DALI2 75 W 220-240 V 12.500 lm 170 lm/W 3.500 K 14.000 lm 190 lm/W 4.000 K 13.500 lm 185 lm/W 5.000 K 10

CRI Ambient temperature Weight Control Emergency lighting Availability* Prod no. EUR 100.000h L80B10 >80 5*2,5 mm² -20° + 40°C 2,8 kg On / Off S 1009207 200.00 100.000h L80B10 >80 5*2,5 mm² -20° + 40°C 2,8 kg On / Off O 1009208 200.00 100.000h L80B10 >80 5*2,5 mm² -20° + 40°C 2,8 kg On / Off S 1009209 200.00 100.000h L80B10 >80 5*2,5 mm² -20° + 40°C 2,8 kg On / Off S 1009210 200.00 100.000h L80B10 >80 5*2,5 mm² -20° + 40°C 2,8 kg On / Off O 1009211 200.00 100.000h L80B10 >80 7*2,5 mm² -20° + 40°C 2,8 kg DALI S 1009212 250.00 100.000h L80B10 >80 7*2,5 mm² -20° + 40°C 2,8 kg DALI O 1009213 250.00 100.000h L80B10 >80 7*2,5 mm² -20° + 40°C 2,8 kg DALI S 1009214 250.00 100.000h L80B10 >80 7*2,5 mm² -20° + 40°C 2,8 kg DALI S 1009215 250.00 100.000h L80B10 >80 7*2,5 mm² -20° + 40°C 2,8 kg DALI O 1009216 250.00 11

IP40 IK06 INDOOR EASYLIGHT EASYLIGHT Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature EASYLIGHT 2500 140 835/840/850 WB WH ML 80 W 220-240 V 14.000 lm 175 lm/W 3.500 K 15.000 lm 190 lm/W 4.000 K 15.000 lm 190 lm/W 5.000 K EASYLIGHT 2500 140 835/840/850 NB WH ML 80 W 220-240 V 14.000 lm 175 lm/W 3.500 K 15.000 lm 190 lm/W 4.000 K 15.000 lm 190 lm/W 5.000 K EASYLIGHT 2500 140 835/840/850 MB WH ML 80 W 220-240 V 14.000 lm 175 lm/W 3.500 K 15.000 lm 190 lm/W 4.000 K 15.000 lm 190 lm/W 5.000 K EASYLIGHT 2500 140 835/840/850 OVAL WH ML 80 W 220-240 V 14.000 lm 175 lm/W 3.500 K 15.000 lm 190 lm/W 4.000 K 15.000 lm 190 lm/W 5.000 K EASYLIGHT 2500 140 835/840/850 DA30 WH ML 80 W 220-240 V 14.000 lm 175 lm/W 3.500 K 15.000 lm 190 lm/W 4.000 K 15.000 lm 190 lm/W 5.000 K EASYLIGHT 2500 150 835/840/850 WB WH ML DALI2 80 W 220-240 V 14.000 lm 175 lm/W 3.500 K 15.000 lm 190 lm/W 4.000 K 15.000 lm 190 lm/W 5.000 K EASYLIGHT 2500 150 835/840/850 NB WH ML DALI2 80 W 220-240 V 14.000 lm 175 lm/W 3.500 K 15.000 lm 190 lm/W 4.000 K 15.000 lm 190 lm/W 5.000 K EASYLIGHT 2500 150 835/840/850 MB WH ML DALI2 80 W 220-240 V 14.000 lm 175 lm/W 3.500 K 15.000 lm 190 lm/W 4.000 K 15.000 lm 190 lm/W 5.000 K EASYLIGHT 2500 150 835/840/850 OVAL WH ML DALI2 80 W 220-240 V 14.000 lm 175 lm/W 3.500 K 15.000 lm 190 lm/W 4.000 K 15.000 lm 190 lm/W 5.000 K EASYLIGHT 2500 150 835/840/850 DA30 WH ML DALI2 80 W 220-240 V 14.000 lm 175 lm/W 3.500 K 15.000 lm 190 lm/W 4.000 K 15.000 lm 190 lm/W 5.000 K *S = in stock O = to order 12

CRI Ambient temperature Weight Control Emergency lighting Availability* Prod no. EUR 100.000h L80B10 >80 5*2,5 mm² -20° + 40°C 4,6 kg On / Off S 1009217 320.00 100.000h L80B10 >80 5*2,5 mm² -20° + 40°C 4,6 kg On / Off O 1009218 320.00 100.000h L80B10 >80 5*2,5 mm² -20° + 40°C 4,6 kg On / Off S 1009219 320.00 100.000h L80B10 >80 5*2,5 mm² -20° + 40°C 4,6 kg On / Off S 1009220 320.00 100.000h L80B10 >80 5*2,5 mm² -20° + 40°C 4,6 kg On / Off O 1009221 320.00 100.000h L80B10 >80 7*2,5 mm² -20° + 40°C 4,6 kg DALI S 1009222 370.00 100.000h L80B10 >80 7*2,5 mm² -20° + 40°C 4,6 kg DALI O 1009223 370.00 100.000h L80B10 >80 7*2,5 mm² -20° + 40°C 4,6 kg DALI S 1009224 370.00 100.000h L80B10 >80 7*2,5 mm² -20° + 40°C 4,6 kg DALI S 1009225 370.00 100.000h L80B10 >80 7*2,5 mm² -20° + 40°C 4,6 kg DALI O 1009226 370.00 13

300 x 65 x 60 1.500 x 65 x 42 2.500 x 65 x 42 4.500 x 65 x 42 65 x 60 300 x 65 x 60 436 x 65 x 60 436 x 65 x 60 EASYLIGHT INDOOR Product designation Colour Availability* Prod no. EUR EASYLIGHT FIB 300 5 25 WH S 1009230 45.00 EASYLIGHT FIB 300 7 25 WH S 1009231 45.00 EASYLIGHT FOB 300 5 25 WH S 1009232 55.00 EASYLIGHT FOB 300 7 25 WH S 1009233 65.00 Product designation Colour Availability* Prod no. EUR EASYLIGHT BC 1500 5 25 WH S 1009234 50.00 EASYLIGHT BC 1500 7 25 WH S 1009235 58.00 EASYLIGHT BC 2500 5 25 WH S 1009236 75.00 EASYLIGHT BC 2500 7 25 WH S 1009237 85.00 EASYLIGHT BC 4500 5 25 WH O 1009238 120.00 EASYLIGHT BC 4500 7 25 WH O 1009239 135.00 EASYLIGHT EC WH O 1009240 5.00 L x W x H (mm): L x W x H (mm): L x W x H (mm): L x W x H (mm): W x H (mm): L x W x H (mm): L x W x H (mm): L x W x H (mm): An extensive range of accessories, such as emergency lighting modules and spotlights, is available on request. *S = in stock O = to order 14

Product designation Colour Availability* Prod no. EUR EASYLIGHT CSK S 1009241 8.00 EASYLIGHT CSK FT S 1009242 11.00 EASYLIGHT SCK 5000 O 1009247 18.00 EASYLIGHT SCF M6 S 1009244 7.00 EASYLIGHT SCF M10 S 1009245 7.00 EASYLIGHT STM O 1009246 7.00 15

Simply remove the old light carrier and replace it with RETRO.

3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K C0-C180 C0-C180 WB Oval MB NB 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K C0-C180 C0-C180 WB Oval MB NB 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K C0-C180 C0-C180 WB Oval MB NB 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K 3.500 K | 5.000 K 4.000 K C0-C180 C0-C180 WB Oval MB NB RETRO PRODUCT ADVANTAGES 1:1 replacement of existing T8/T5 continuous-row systems in under 1 minute Compatible with standard trunking from well-known manufacturers High energy savings thanks to an E ciency of up to 190 lm/W Service life up to 100,000 hours EASY TO INSTALL Thanks to Click Design for tool-free installation Flexibly customisable thanks to four diŸerent beam angles Multi-Lumen and Multi-Colour DALI-dimmable and DC-capable up to 190 lm/W BEAM ANGLE Wide light distribution for open areas such as supermarkets, logistics areas and showrooms. Ideal for uniform ambient lighting. Balanced light distribution for production areas and workshops where uniform and e˜cient illumination over a medium width is required. Focused light distribution for targeted illumination of high aisles or storage areas with narrow geometries – particularly eŸective at great heights. Elongated light distribution for corridors, hallways and busy areas – optimised for linear room geometries with uniform light distribution. 17

RETRO The quickest way to modernise a lighting system. The RETRO LED system was specially developed for quick and easy retrofitting of existing T8 and T5 continuous-row lighting systems. Thanks to the ingenious Click Design, replacement is possible in less than a minute - no tools or conversions required. The modules are compatible with a wide range of popular trunking systems and oŸer a significantly higher e˜ciency of up to 190 lm/W. Output and light colour can be adjusted on site using the power and CCT switch for maximum project flexibility. Various beam angles, DALI options and a service life of up to 100,000 hours make RETRO the ideal solution for demanding modernisation projects in industry, retail and logistics. RETRO AT A GLANCE 1:1 replacement for existing T8/T5 fluorescent lamps Compatible with top brand trunking Up to 190 lm/W luminous e˜ciency Click assembly without tools Integrated power and CCT switch Various beam angles and lengths for maximum flexibility 1:1 SOLUTION With the RETRO LED module, you can convert your existing trunking system to LED with no tools in just 44 seconds! Remove old light Ensure that male and female plugs are positioned correctly Click the new LED module into existing trunking Done 18

A=1475mm B=1478mm C=1484mm D=1494mm E=1520mm F=1525mm G=1528mm H=1530mm I=1534mm J=1537mm A=1475mm B=1478mm C=1484mm D=1494mm E=1520mm F=1525mm G=1528mm H=1530mm I=1534mm J=1537mm A=1475mm B=1478mm C=1484mm D=1494mm E=1520mm F=1525mm G=1528mm H=1530mm I=1534mm J=1537mm A=1475mm B=1478mm C=1484mm D=1494mm E=1520mm F=1525mm G=1528mm H=1530mm I=1534mm J=1537mm 5mm m A=1475mm B=1478mm C=1484mm D=1494mm E=1520mm F=1525mm G=1528mm H=1530mm I=1534mm J=1537mm A=1475mm B=1478mm C=1484mm D=1494mm E=1520mm F=1525mm G=1528mm H=1530mm I=1534mm J=1537mm A=1475mm B=1478mm C=1484mm D=1494mm E=1520mm F=1525mm G=1528mm H=1530mm I=1534mm J=1537mm A=1475mm B=1478mm C=1484mm D=1494mm E=1520mm F=1525mm G=1528mm H=1530mm I=1534mm J=1537mm A=1475mm B=1478mm C=1484mm D=1494mm E=1520mm F=1525mm G=1528mm H=1530mm I=1534mm J=1537mm “Click” A=1475mm B=1478mm C=1484mm D=1494mm E=1520mm F=1525mm G=1528mm H=1530mm I=1534mm J=1537mm A=1475mm B=1478mm C=1484mm D=1494mm E=1520mm F=1525mm G=1528mm H=1530mm I=1534mm J=1537mm A=1475mm B=1478mm C=1484mm D=1494mm E=1520mm F=1525mm G=1528mm H=1530mm I=1534mm J=1537mm A=1475mm B=1478mm C=1484mm D=1494mm E=1520mm F=1525mm G=1528mm H=1530mm I=1534mm J=1537mm “Click” Length adjustable Easy adjustment to the desired length 1175 mm to 1237 mm 1475 mm to 1537 mm High-output lighting technology with four diŸerent beam angles Plug-and-play connector system for diŸerent trunking Intelligent Click Design for tool-free assembly Robust housing in white similar to RAL 9016 Luminous flux adjustable via DIP switch CCT switch 3,500 K – 4,000 K – 5,000 K 19

IP20 IK04 INDOOR RETRO RETRO Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature RETRO LT 1200 110 835/840/850 WB ML WH 61 W 220-240 V 10.200 lm 170 lm/W 3.500 K 11.000 lm 185 lm/W 4.000 K 10.800 lm 180 lm/W 5.000 K RETRO LT 1200 110 835/840/850 MB ML WH 61 W 220-240 V 10.200 lm 170 lm/W 3.500 K 11.000 lm 185 lm/W 4.000 K 10.800 lm 180 lm/W 5.000 K RETRO LT 1200 110 835/840/850 NB ML WH 61 W 220-240 V 10.200 lm 170 lm/W 3.500 K 11.000 lm 185 lm/W 4.000 K 10.800 lm 180 lm/W 5.000 K RETRO LT 1200 110 835/840/850 OVAL ML WH 61 W 220-240 V 10.200 lm 170 lm/W 3.500 K 11.000 lm 185 lm/W 4.000 K 10.800 lm 180 lm/W 5.000 K RETRO LT 1200 107 835/840/850 WB ML WH DALI 60 W 220-240 V 10.300 lm 173 lm/W 3.500 K 11.400 lm 190 lm/W 4.000 K 11.000 lm 185 lm/W 5.000 K RETRO LT 1200 107 835/840/850 MB ML WH DALI 60 W 220-240 V 10.300 lm 173 lm/W 3.500 K 11.400 lm 190 lm/W 4.000 K 11.000 lm 185 lm/W 5.000 K RETRO LT 1200 107 835/840/850 NB ML WH DALI 60 W 220-240 V 10.300 lm 173 lm/W 3.500 K 11.400 lm 190 lm/W 4.000 K 11.000 lm 185 lm/W 5.000 K RETRO LT 1200 107 835/840/850 OVAL ML WH DALI 60 W 220-240 V 10.300 lm 173 lm/W 3.500 K 11.400 lm 190 lm/W 4.000 K 11.000 lm 185 lm/W 5.000 K *S = in stock O = to order 20

CRI Ambient temperature Weight Control Emergency lighting Availability* Prod no. EUR 100.000h L80B10 >80 3-adrig -20° + 40°C 1,4 kg On / Off O 1009179 160.00 100.000h L80B10 >80 3-adrig -20° + 40°C 1,4 kg On / Off O 1009180 160.00 100.000h L80B10 >80 3-adrig -20° + 40°C 1,4 kg On / Off O 1009181 160.00 100.000h L80B10 >80 3-adrig -20° + 40°C 1,4 kg On / Off O 1009182 160.00 100.000h L80B10 >80 5-adrig -20° + 40°C 1,4 kg DALI O 1009183 210.00 100.000h L80B10 >80 5-adrig -20° + 40°C 1,4 kg DALI O 1009184 210.00 100.000h L80B10 >80 5-adrig -20° + 40°C 1,4 kg DALI O 1009185 210.00 100.000h L80B10 >80 5-adrig -20° + 40°C 1,4 kg DALI O 1009186 210.00 21

IP20 IK04 INDOOR RETRO RETRO Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature RETRO LT 1500 135 835/840/850 WB ML WH 75 W 220-240 V 10.700 lm 173 lm/W 3.500 K 11.700 lm 192 lm/W 4.000 K 11.500 lm 185 lm/W 5.000 K RETRO LT 1500 135 835/840/850 MB ML WH 75 W 220-240 V 10.700 lm 173 lm/W 3.500 K 11.700 lm 192 lm/W 4.000 K 11.500 lm 185 lm/W 5.000 K RETRO LT 1500 135 835/840/850 NB ML WH 75 W 220-240 V 10.700 lm 173 lm/W 3.500 K 11.700 lm 192 lm/W 4.000 K 11.500 lm 185 lm/W 5.000 K RETRO LT 1500 135 835/840/850 OVAL ML WH 75 W 220-240 V 10.700 lm 173 lm/W 3.500 K 11.700 lm 192 lm/W 4.000 K 11.500 lm 185 lm/W 5.000 K RETRO LT 1500 133 835/840/850 WB ML WH DALI 75 W 220-240 V 12.800 lm 170 lm/W 3.500 K 13.800 lm 185 lm/W 4.000 K 13.500 lm 180 lm/W 5.000 K RETRO LT 1500 133 835/840/850 MB ML WH DALI 75 W 220-240 V 12.800 lm 170 lm/W 3.500 K 13.800 lm 185 lm/W 4.000 K 13.500 lm 180 lm/W 5.000 K RETRO LT 1500 133 835/840/850 NB ML WH DALI 75 W 220-240 V 12.800 lm 170 lm/W 3.500 K 13.800 lm 185 lm/W 4.000 K 13.500 lm 180 lm/W 5.000 K RETRO LT 1500 133 835/840/850 OVAL ML WH DALI 75 W 220-240 V 12.800 lm 170 lm/W 3.500 K 13.800 lm 185 lm/W 4.000 K 13.500 lm 180 lm/W 5.000 K *S = in stock O = to order 22

CRI Ambient temperature Weight Control Emergency lighting Availability* Prod no. EUR 100.000h L80B10 >80 3-adrig -20° + 40°C 1,7 kg On / Off O 1009187 180.00 100.000h L80B10 >80 3-adrig -20° + 40°C 1,7 kg On / Off O 1009188 180.00 100.000h L80B10 >80 3-adrig -20° + 40°C 1,7 kg On / Off O 1009189 180.00 100.000h L80B10 >80 3-adrig -20° + 40°C 1,7 kg On / Off O 1009190 180.00 100.000h L80B10 >80 5-adrig -20° + 40°C 1,7 kg DALI O 1009191 220.00 100.000h L80B10 >80 5-adrig -20° + 40°C 1,7 kg DALI O 1009192 220.00 100.000h L80B10 >80 5-adrig -20° + 40°C 1,7 kg DALI O 1009193 220.00 100.000h L80B10 >80 5-adrig -20° + 40°C 1,7 kg DALI O 1009194 220.00 23

INDOOR RETRO Product designation Colour Availability* Prod no. EUR RETRO CON 3P001 S 1009195 17.00 RETRO CON 3P002 S 1009196 17.00 RETRO CON 3P003 S 1009197 17.00 RETRO CON 3P004 S 1009198 17.00 RETRO CON 3P005 S 1009199 17.00 RETRO CON 3P006 S 1009200 17.00 RETRO CON 3P007 S 1009201 17.00 CONNECTORS FOR ON / OFF *S = in stock O = to order 24

Product designation Colour Availability* Prod no. EUR RETRO CON 5P101 O 1009202 22.00 RETRO CON 5P102 O 1009203 22.00 RETRO CON 5P103 O 1009204 22.00 RETRO CON 5P104 O 1009205 22.00 RETRO CON 5P105 O 1009206 22.00 CONNECTORS FOR DALI 25

When purchasing a PANEL the mounting frame is not included as standard. PANEL COMBINE surface-mounted or recessed mounting frame

PRODUCT VARIANTS PANEL PRODUCT ADVANTAGES High energy savings thanks to an e ciency of up to 200 lm/W (depending on model at least 120 lm/W) Especially high energy savings when using the PANEL P Can be used as o ce lighting thanks to UGR<19 EASY TO INSTALL thanks to integrated through-wiring and external ballast Flexibly adjustable thanks to Multi-Lumen (all variants) and Multi-Colour (PANEL V & C) All DALI variants support DC operation up to 200 lm/W PANEL V PANEL C PANEL P Service life 50.000h L80B10 70.000h L80B10 100.000h L80B50 Energy efficiency up to 126 lm/W up to 136 lm/W up to 203 lm/W UGR <19 / <22 <19 <19 Control Multi-Lumen, On / OŸ, DALI Multi-Lumen, On / OŸ, DALI Multi-Lumen, On / OŸ, DALI 27

600 x 600 x 63 600 x 600 x 71 625 x 625 x 63 625 x 625 x 71 IP40/54 IK03 INDOOR PANEL V PANEL Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature PANEL V 600 830 / 840, 34 W 34 W 220-240 V 4.100 lm 121 lm/W 3.000 K 4.300 lm 126 lm/W 4.000 K PANEL V 600 830 / 840, 34 W, UGR 34 W 220-240 V 4.000 lm 118 lm/W 3.000 K 4.200 lm 124 lm/W 4.000 K PANEL V DALI 600 830 / 840, 34 W, UGR 34 W 220-240 V 4.000 lm 118 lm/W 3.000 K 4.200 lm 124 lm/W 4.000 K PANEL V 625 830 / 840, 34 W 34 W 220-240 V 4.100 lm 121 lm/W 3.000 K 4.300 lm 126 lm/W 4.000 K PANEL V 625 830 / 840, 34 W, UGR 34 W 220-240 V 4.000 lm 118 lm/W 3.000 K 4.200 lm 124 lm/W 4.000 K PANEL V DALI 625 830 / 840, 34 W, UGR 34 W 220-240 V 4.000 lm 118 lm/W 3.000 K 4.200 lm 124 lm/W 4.000 K Product designation Colour Availability* Prod no. EUR PANEL 600 Mounting frame S 1007474 45.00 PANEL 600 Recessed mounting frames S 1007575 65.00 PANEL 625 Mounting frame S 1007475 45.00 PANEL 625 Recessed mounting frames S 1007576 65.00 L x W x H (mm): L x W x H (mm): L x W x H (mm): L x W x H (mm): All mounting frames are also compatible with Panel C and Panel P. *S = in stock O = to order 28

1,5 x 1500 CRI UGR Control Emergency lighting Availability* Prod no. EUR 50.000h L80B10 >80 <22 115° - - On / Off S 1007496 65.00 50.000h L80B10 >80 <19 85° - - On / Off S 1007498 75.00 50.000h L80B10 >80 <19 85° - - DALI S 1007504 110.00 50.000h L80B10 >80 <22 115° - - On / Off S 1007497 65.00 50.000h L80B10 >80 <19 85° - - On / Off S 1007499 75.00 50.000h L80B10 >80 <19 85° - - DALI S 1007505 110.00 Product designation Colour Availability* Prod no. EUR PANEL V Safety cable 1500 mm S 1007577 15.00 Ø x L (mm): 29

IP40/54 IK02 INDOOR PANEL Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature PANEL C 600 34 W, 830 / 840, UGR 34 W 220-240 V 4.550 lm 133 lm/W 3.000 K 4.650 lm 136 lm/W 4.000 K PANEL C 600 34 W, 930 / 940, UGR 34 W 220-240 V 4.300 lm 126 lm/W 3.000 K 4.500 lm 132 lm/W 4.000 K PANEL C DALI 600 34 W, 830 / 840, UGR 34 W 220-240 V 4.550 lm 133 lm/W 3.000 K 4.650 lm 136 lm/W 4.000 K PANEL C 600 DALI 34 W, 930 / 940, UGR 34 W 220-240 V 4.300 lm 126 lm/W 3.000 K 4.500 lm 132 lm/W 4.000 K PANEL C 625 34 W, 830 / 840, UGR 34 W 220-240 V 4.550 lm 133 lm/W 3.000 K 4.650 lm 136 lm/W 4.000 K PANEL C 625 34 W, 930 / 940, UGR 34 W 220-240 V 4.300 lm 126 lm/W 3.000 K 4.500 lm 132 lm/W 4.000 K PANEL C DALI 625 34 W, 830 / 840, UGR 34 W 220-240 V 4.550 lm 133 lm/W 3.000 K 4.650 lm 136 lm/W 4.000 K PANEL C 625 DALI 34 W, 930 / 940, UGR 34 W 220-240 V 4.300 lm 126 lm/W 3.000 K 4.500 lm 132 lm/W 4.000 K PANEL C 1200 34 W, 830 / 840, UGR 34 W 220-240 V 4.550 lm 133 lm/W 3.000 K 4.650 lm 129 lm/W 4.000 K PANEL C 1200 34 W, 930 / 940, UGR 34 W 220-240 V 4.200 lm 123 lm/W 3.000 K 4.400 lm 129 lm/W 4.000 K PANEL C 1200 DALI 34 W, 830 / 840, UGR 34 W 220-240 V 4.550 lm 133 lm/W 3.000 K 4.650 lm 129 lm/W 4.000 K PANEL C 1200 DALI 34 W, 930 / 940, UGR 34 W 220-240 V 4.200 lm 123 lm/W 3.000 K 4.400 lm 129 lm/W 4.000 K The matching mounting frames can be found on page 28. PANEL C *S = in stock O = to order 30

1,5 x 1500 4 x 3,5 x 3,2 620 620 28 295 28 1195 CRI UGR Emergency lighting Control Availability* Prod no. EUR 70.000h L80B10 >80 <19 90° - - On / Off S 1008597 114.00 70.000h L80B10 >90 <19 90° - - On / Off S 1008599 114.00 70.000h L80B10 >80 <19 90° - - DALI S 1008601 139.00 70.000h L80B10 >90 <19 90° - - DALI S 1008603 139.00 70.000h L80B10 >80 <19 90° - - On / Off S 1008598 114.00 70.000h L80B10 >90 <19 90° - - On / Off S 1008600 114.00 70.000h L80B10 >80 <19 90° - - DALI S 1008602 139.00 70.000h L80B10 >90 <19 90° - - DALI S 1008604 139.00 70.000h L80B10 >80 <19 90° - - On / Off S 1008605 114.00 70.000h L80B10 >90 <19 90° - - On / Off S 1008606 114.00 70.000h L80B10 >80 <19 90° - - DALI S 1008607 139.00 70.000h L80B10 >90 <19 90° - - DALI S 1008608 139.00 Product designation Colour Availability* Prod no. EUR PANEL C Suspension cable 1500 mm S 1008609 19.90 PANEL C Mounting spring 4 pieces S 1008610 14.90 Ø x L (mm): L x W x H (cm): 31

INDOOR PANEL Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature PANEL P 595 45 840 WB UGR19 ML WH 42 W 220-240 V 6.900 lm 203 lm/W 4.000 K PANEL P 595 45 830 WB UGR19 ML WH 42 W 220-240 V 6.500 lm 203 lm/W 3.000 K PANEL P 595 45 840 WB UGR19 ML DALI WH 42 W 220-240 V 6.900 lm 200 lm/W 4.000 K PANEL P 595 45 830 WB UGR19 ML DALI WH 42 W 220-240 V 6.500 lm 200 lm/W 3.000 K PANEL P 625 45 840 WB UGR19 ML WH 42 W 220-240 V 6.900 lm 203 lm/W 4.000 K PANEL P 625 45 830 WB UGR19 ML WH 42 W 220-240 V 6.500 lm 203 lm/W 3.000 K PANEL P 625 45 840 WB UGR19 ML DALI WH 42 W 220-240 V 6.900 lm 200 lm/W 4.000 K PANEL P 625 45 830 WB UGR19 ML DALI WH 42 W 220-240 V 6.500 lm 200 lm/W 3.000 K PANEL P 1200/300 45 840 WB UGR19 ML WH 42 W 220-240 V 6.700 lm 190 lm/W 4.000 K PANEL P 1200/300 45 830 WB UGR19 ML WH 42 W 220-240 V 6.400 lm 190 lm/W 3.000 K PANEL P 1200/300 45 840 WB UGR19 ML DALI WH 42 W 220-240 V 6.700 lm 200 lm/W 4.000 K PANEL P 1200/300 45 830 WB UGR19 ML DALI WH 42 W 220-240 V 6.400 lm 200 lm/W 3.000 K PANEL P 1200/600 60 840 WB UGR19 ML WH 42 W 220-240 V 7.000 lm 203 lm/W 4.000 K PANEL P 1200/600 60 830 WB UGR19 ML WH 42 W 220-240 V 6.700 lm 203 lm/W 3.000 K PANEL P 1200/600 60 840 WB UGR19 ML DALI WH 42 W 220-240 V 7.000 lm 203 lm/W 4.000 K PANEL P 1200/600 60 830 WB UGR19 ML DALI WH 42 W 220-240 V 6.700 lm 203 lm/W 3.000 K PANEL P IP20 IK02 The matching mounting frames can be found on page 28. *S = in stock O = to order 32

8 36 620 620 8 36 595 595 1195 295 8 36 1195 295 8 36 1195 595 8 36 1195 595 8 36 CRI UGR Emergency lighting Control Availability* Prod no. EUR 100.000h L80B50 >80 <19 110° - - On / Off S 1010747 130.00 100.000h L80B50 >80 <19 110° - - On / Off S 1010748 130.00 100.000h L80B50 >80 <19 110° - - DALI S 1010749 150.00 100.000h L80B50 >80 <19 110° - - DALI S 1010750 150.00 100.000h L80B50 >80 <19 110° - - On / Off S 1010109 130.00 100.000h L80B50 >80 <19 110° - - On / Off O 1010110 130.00 100.000h L80B50 >80 <19 110° - - DALI S 1010111 150.00 100.000h L80B50 >80 <19 110° - - DALI O 1010112 150.00 100.000h L80B50 >80 <19 110° - - On / Off S 1010113 140.00 100.000h L80B50 >80 <19 110° - - On / Off O 1010114 140.00 100.000h L80B50 >80 <19 110° - - DALI S 1010115 160.00 100.000h L80B50 >80 <19 110° - - DALI O 1010116 160.00 100.000h L80B50 >80 <19 110° - - On / Off O 1010117 170.00 100.000h L80B50 >80 <19 110° - - On / Off O 1010118 170.00 100.000h L80B50 >80 <19 110° - - DALI O 1010119 200.00 100.000h L80B50 >80 <19 110° - - DALI O 1010120 200.00 33

Multi-Colour: 3.000 K / 4.000 K / 5.000 K

PAVANNO PRODUCT ADVANTAGES High energy savings thanks to an E ciency of up to 190 lm/W Can be used as o ce lighting thanks to UGR<19 Service life up to 100,000 hours EASY TO INSTALL thanks to integrated through-wiring and external ballast Flexibly adjustable thanks to Multi-Lumen and Multi-Colour All DALI variants support DC operation Service life 100,000 hours 35

IP20 IK02 INDOOR PAVANNO PAVANNO Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature PAVANNO 600 45 830/840/850 WB WH UGR19 39 W 220-240 V 6.600 lm 180 lm/W 3.000 K 6.900 lm 190 lm/W 4.000 K 6.900 lm 190 lm/W 5.000 K PAVANNO 600 45 830/840/850 WB WH UGR19 DALI 38 W 220-240 V 6.300 lm 175 lm/W 3.000 K 6.800 lm 185 lm/W 4.000 K 6.800 lm 185 lm/W 5.000 K PAVANNO 600 45 830/840/850 WB BK, UGR19 39 W 220-240 V 6.200 lm 170 lm/W 3.000 K 6.600 lm 180 lm/W 4.000 K 6.600 lm 180 lm/W 5.000 K PAVANNO 600 45 830/840/850 WB BK, UGR19 DALI 38 W 220-240 V 6.000 lm 160 lm/W 3.000 K 6.400 lm 170 lm/W 4.000 K 6.400 lm 170 lm/W 5.000 K PAVANNO 625 45 830/840/850 WB WH UGR19 39 W 220-240 V 6.600 lm 180 lm/W 3.000 K 6.900 lm 190 lm/W 4.000 K 6.900 lm 190 lm/W 5.000 K PAVANNO 625 45 830/840/850 WB WH UGR19 DALI 38 W 220-240 V 6.300 lm 175 lm/W 3.000 K 6.800 lm 185 lm/W 4.000 K 6.800 lm 185 lm/W 5.000 K PAVANNO 1200/300 45 830/840/850 WB WH UGR19 39 W 220-240 V 6.600 lm 180 lm/W 3.000 K 6.900 lm 190 lm/W 4.000 K 6.900 lm 190 lm/W 5.000 K PAVANNO 1200/300 45 830/840/850 WB WH UGR19 DALI 38 W 220-240 V 6.300 lm 175 lm/W 3.000 K 6.800 lm 185 lm/W 4.000 K 6.800 lm 185 lm/W 5.000 K Other sizes are available on request. *S = in stock O = to order 36

10 595 595 20 10 620 620 20 10 1195 295 20 CRI UGR Control Emergency lighting Availability* Prod no. EUR 100.000h L80B10 >80 19 80° - - On / Off S 1010713 195.00 100.000h L80B10 >80 19 80° - - DALI S 1010714 200.00 100.000h L80B10 >80 19 80° - - On / Off S 1010716 195.00 100.000h L80B10 >80 19 80° - - DALI S 1010715 200.00 100.000h L80B10 >80 19 80° - - On / Off S 1010121 185.00 100.000h L80B10 >80 19 80° - - DALI S 1010122 200.00 100.000h L80B10 >80 19 80° - - On / Off S 1010123 235.00 100.000h L80B10 >80 19 80° - - DALI S 1010124 250.00 37

With 36° or 50° beam angle

TRACKSPOT PRODUCT ADVANTAGES 54 Product variants - for maximum flexibility and customised use Outstanding light quality thanks to CRI>90 Simple and timeless design 90° vertically and 355° horizontally rotatable PRODUCT VARIANTS TRACKSPOT V TRACKSPOT C TRACKSPOT P Service life 50.000h L70B50 50.000h L70B50 75.000h L80B10 Energy efficiency up to 130 lm/W up to 152 lm/W up to 170 lm/W CRI >90 >90 >90 Control On / OŸ On / OŸ On / OŸ 39

IP20 IK02 INDOOR TRACKSPOT Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature TRACKSPOT V 3-ph, 18 W, 930, 36°, white 18 W 220-240 V 2.250 lm 125 lm/W 3.000 K TRACKSPOT V 3-ph, 18 W, 930, 36°, black 18 W 220-240 V 2.250 lm 125 lm/W 3.000 K TRACKSPOT V 3-ph, 18 W, 930, 50°, white 18 W 220-240 V 2.250 lm 125 lm/W 3.000 K TRACKSPOT V 3-ph, 18 W, 930, 50°, black 18 W 220-240 V 2.250 lm 125 lm/W 3.000 K TRACKSPOT V 3-ph, 18 W, 940, 36°, white 18 W 220-240 V 2.350 lm 130 lm/W 4.000 K TRACKSPOT V 3-ph, 18 W, 940, 36°, black 18 W 220-240 V 2.350 lm 130 lm/W 4.000 K TRACKSPOT V 3-ph, 18 W, 940, 50°, white 18 W 220-240 V 2.350 lm 130 lm/W 4.000 K TRACKSPOT V 3-ph, 18 W, 940, 50°, black 18 W 220-240 V 2.350 lm 130 lm/W 4.000 K TRACKSPOT V 3-ph, 32 W, 930, 36°, white 32 W 220-240 V 3.700 lm 115 lm/W 3.000 K TRACKSPOT V 3-ph, 32 W, 930, 36°, black 32 W 220-240 V 3.700 lm 115 lm/W 3.000 K TRACKSPOT V 3-ph, 32 W, 930, 50°, white 32 W 220-240 V 3.700 lm 115 lm/W 3.000 K TRACKSPOT V 3-ph, 32 W, 930, 50°, black 32 W 220-240 V 3.700 lm 115 lm/W 3.000 K TRACKSPOT V 3-ph, 32 W, 940, 36°, white 32 W 220-240 V 3.900 lm 121 lm/W 4.000 K TRACKSPOT V 3-ph, 32 W, 940, 36°, black 32 W 220-240 V 3.900 lm 121 lm/W 4.000 K TRACKSPOT V 3-ph, 32 W, 940, 50°, white 32 W 220-240 V 3.900 lm 121 lm/W 4.000 K TRACKSPOT V 3-ph, 32 W, 940, 50°, black 32 W 220-240 V 3.900 lm 121 lm/W 4.000 K TRACKSPOT V *S = in stock O = to order 40

100 105 140 CRI UGR Control Emergency lighting Availability* Prod no. EUR 50.000h L70B50 >90 - 36° - 90° On / Off S 1008844 90.00 50.000h L70B50 >90 - 36° - 90° On / Off S 1008845 90.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008846 90.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008847 90.00 50.000h L70B50 >90 - 36° - 90° On / Off S 1008848 90.00 50.000h L70B50 >90 - 36° - 90° On / Off S 1008849 90.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008850 90.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008851 90.00 50.000h L70B50 >90 - 36° - 90° On / Off S 1008852 110.00 50.000h L70B50 >90 - 36° - 90° On / Off S 1008853 110.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008854 110.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008855 110.00 50.000h L70B50 >90 - 36° - 90° On / Off S 1008856 110.00 50.000h L70B50 >90 - 36° - 90° On / Off S 1008857 110.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008858 110.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008859 110.00 41

INDOOR TRACKSPOT Product designation Colour Max. otal wattage Mains voltage Max. flux Efficiency Colour temperature TRACKSPOT C 3-ph, 17 W, 930, 36°, white 17 W 220-240 V 2.450 lm 144 lm/W 3.000 K TRACKSPOT C 3-ph, 17 W, 930, 36°, black 17 W 220-240 V 2.450 lm 144 lm/W 3.000 K TRACKSPOT C 3-ph, 17 W, 930, 50°, white 17 W 220-240 V 2.450 lm 144 lm/W 3.000 K TRACKSPOT C 3-ph, 17 W, 930, 50°, black 17 W 220-240 V 2.450 lm 144 lm/W 3.000 K TRACKSPOT C 3-ph, 17 W, 940, 36°, white 17 W 220-240 V 2.600 lm 152 lm/W 4.000 K TRACKSPOT C 3-ph, 17 W, 940, 36°, black 17 W 220-240 V 2.600 lm 152 lm/W 4.000 K TRACKSPOT C 3-ph, 17 W, 940, 50°, white 17 W 220-240 V 2.600 lm 152 lm/W 4.000 K TRACKSPOT C 3-ph, 17 W, 940, 50°, black 17 W 220-240 V 2.600 lm 152 lm/W 4.000 K TRACKSPOT C 3-ph, 29 W, 930, 36°, white 29 W 220-240 V 4.050 lm 139 lm/W 3.000 K TRACKSPOT C 3-ph, 29 W, 930, 36°, black 29 W 220-240 V 4.050 lm 139 lm/W 3.000 K TRACKSPOT C 3-ph, 29 W, 930, 50°, white 29 W 220-240 V 4.050 lm 139 lm/W 3.000 K TRACKSPOT C 3-ph, 29 W, 930, 50°, black 29 W 220-240 V 4.050 lm 139 lm/W 3.000 K TRACKSPOT C 3-ph, 29 W, 940, 36°, white 29 W 220-240 V 4.200 lm 144 lm/W 4.000 K TRACKSPOT C 3-ph, 29 W, 940, 36°, black 29 W 220-240 V 4.200 lm 144 lm/W 4.000 K TRACKSPOT C 3-ph, 29 W, 940, 50°, white 29 W 220-240 V 4.200 lm 144 lm/W 4.000 K TRACKSPOT C 3-ph, 29 W, 940, 50°, black 29 W 220-240 V 4.200 lm 144 lm/W 4.000 K TRACKSPOT C IP20 IK02 *S = in stock O = to order 42

100 105 140 CRI UGR Control Emergency lighting Availability* Prod no. EUR 50.000h L70B50 >90 - 36° - 90° On / Off S 1008860 100.00 50.000h L70B50 >90 - 36° - 90° On / Off S 1008861 100.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008862 100.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008863 100.00 50.000h L70B50 >90 - 36° - 90° On / Off S 1008864 100.00 50.000h L70B50 >90 - 36° - 90° On / Off S 1008865 100.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008866 100.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008867 100.00 50.000h L70B50 >90 - 36° - 90° On / Off S 1008868 120.00 50.000h L70B50 >90 - 36° - 90° On / Off S 1008869 120.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008870 120.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008871 120.00 50.000h L70B50 >90 - 36° - 90° On / Off S 1008872 120.00 50.000h L70B50 >90 - 36° - 90° On / Off S 1008873 120.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008874 120.00 50.000h L70B50 >90 - 50° - 90° On / Off S 1008875 120.00 43

IP20 IK03 INDOOR TRACKSPOT Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature TRACKSPOT P 3PH. 33 930 MB ML BK 28 W 220-240 V 4.360 lm 170 lm/W 3.000 K TRACKSPOT P 3PH. 33 930 MB ML WH 28 W 220-240 V 4.360 lm 170 lm/W 3.000 K TRACKSPOT P 3PH. 34 940 MB ML BK 28 W 220-240 V 4.450 lm 170 lm/W 4.000 K TRACKSPOT P 3PH. 34 940 MB ML WH 28 W 220-240 V 4.450 lm 170 lm/W 4.000 K TRACKSPOT P 3PH. 33 930 WB ML BK 28 W 220-240 V 4.330 lm 170 lm/W 3.000 K TRACKSPOT P 3PH. 33 930 WB ML WH 28 W 220-240 V 4.330 lm 170 lm/W 3.000 K TRACKSPOT P 3PH. 34 940 WB ML BK 28 W 220-240 V 4.390 lm 170 lm/W 4.000 K TRACKSPOT P 3PH. 34 940 WB ML WH 28 W 220-240 V 4.390 lm 170 lm/W 4.000 K TRACKSPOT P 3PH. 34 930 VWB ML BK 28 W 220-240 V 4.450 lm 170 lm/W 3.000 K TRACKSPOT P 3PH. 34 930 VWB ML WH 28 W 220-240 V 4.450 lm 170 lm/W 3.000 K TRACKSPOT P 3PH. 34 940 VWB ML BK 28 W 220-240 V 4.540 lm 170 lm/W 4.000 K TRACKSPOT P 3PH. 34 940 VWB ML WH 28 W 220-240 V 4.540 lm 170 lm/W 4.000 K TRACKSPOT P *S = in stock O = to order 44

140 120 158 90 CRI UGR Control Emergency lighting Availability* Prod no. EUR 75.000h L80B10 >90 <25 36° - 90° On / Off S 1010591 150.00 75.000h L80B10 >90 <25 36° - 90° On / Off O 1010592 150.00 75.000h L80B10 >90 <25 36° - 90° On / Off S 1010593 150.00 75.000h L80B10 >90 <25 36° - 90° On / Off S 1010594 150.00 75.000h L80B10 >90 <25 47° - 90° On / Off O 1010599 150.00 75.000h L80B10 >90 <25 47° - 90° On / Off S 1010600 150.00 75.000h L80B10 >90 <25 47° - 90° On / Off O 1010601 150.00 75.000h L80B10 >90 <25 47° - 90° On / Off S 1010602 150.00 75.000h L80B10 >90 <25 60° - 90° On / Off S 1010607 150.00 75.000h L80B10 >90 <25 60° - 90° On / Off O 1010608 150.00 75.000h L80B10 >90 <25 60° - 90° On / Off S 1010609 150.00 75.000h L80B10 >90 <25 60° - 90° On / Off O 1010610 150.00 45

IP20 IK03 INDOOR TRACKSPOT Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature TRACKSPOT P 3PH. 56 930 MB ML BK 35 W 220-240 V 5.640 lm 164 lm/W 3.000 K TRACKSPOT P 3PH. 56 930 MB ML WH 35 W 220-240 V 5.640 lm 164 lm/W 3.000 K TRACKSPOT P 3PH. 57 940 MB ML BK 35 W 220-240 V 5.750 lm 164 lm/W 4.000 K TRACKSPOT P 3PH. 57 940 MB ML WH 35 W 220-240 V 5.750 lm 164 lm/W 4.000 K TRACKSPOT P 3PH. 56 930 WB ML BK 35 W 220-240 V 5.630 lm 164 lm/W 3.000 K TRACKSPOT P 3PH. 56 930 WB ML WH 35 W 220-240 V 5.630 lm 164 lm/W 3.000 K TRACKSPOT P 3PH. 56 940 WB ML BK 35 W 220-240 V 5.670 lm 164 lm/W 4.000 K TRACKSPOT P 3PH. 57 940 WB ML WH 35 W 220-240 V 5.670 lm 164 lm/W 4.000 K TRACKSPOT P 3PH. 57 930 VWB ML BK 35 W 220-240 V 5.750 lm 164 lm/W 3.000 K TRACKSPOT P 3PH. 57 930 VWB ML WH 35 W 220-240 V 5.750 lm 164 lm/W 3.000 K TRACKSPOT P 3PH. 58 940 VWB ML BK 35 W 220-240 V 5.870 lm 164 lm/W 4.000 K TRACKSPOT P 3PH. 58 940 VWB ML WH 35 W 220-240 V 5.870 lm 164 lm/W 4.000 K TRACKSPOT P *S = in stock O = to order 46

140 120 158 90 CRI UGR Control Emergency lighting Availability* Prod no. EUR 75.000h L80B10 >90 <25 36° - 90° On / Off S 1010595 150.00 75.000h L80B10 >90 <25 36° - 90° On / Off S 1010596 150.00 75.000h L80B10 >90 <25 36° - 90° On / Off O 1010597 150.00 75.000h L80B10 >90 <25 36° - 90° On / Off S 1010598 150.00 75.000h L80B10 >90 <25 47° - 90° On / Off O 1010603 150.00 75.000h L80B10 >90 <25 47° - 90° On / Off S 1010604 150.00 75.000h L80B10 >90 <25 47° - 90° On / Off S 1010605 150.00 75.000h L80B10 >90 <25 47° - 90° On / Off O 1010606 150.00 75.000h L80B10 >90 <25 60° - 90° On / Off O 1010611 150.00 75.000h L80B10 >90 <25 60° - 90° On / Off O 1010612 150.00 75.000h L80B10 >90 <25 60° - 90° On / Off O 1010613 150.00 75.000h L80B10 >90 <25 60° - 90° On / Off O 1010614 150.00 47

DOWNLIGHT V 100 / 150 / 200 When purchasing a DOWNLIGHT the mounting frame is not included as standard. COMBINE Flat or recessed bezels in three sizes and two colours each

DOWNLIGHT PRODUCT ADVANTAGES Easy change between the slightly recessed and flat bezels thanks to the bayonet lock on DOWNLIGHT V EASY TO INSTALL due to the LED driver‘s integrated quick-connect connection box Less rework on site due to Common installation diameters Flexibly adjustable thanks to Multi-Lumen (all versions) and Multi-Colour (Downlight V) DOWNLIGHT V DOWNLIGHT C DOWNLIGHT P Service life 50.000h L70B50 70.000h L80B10 80.000h L80B10 Energy efficiency up to 126 lm/W up to 129 lm/W up to 170 lm/W UGR >28 22 21 / 23 Control On / OŸ On / OŸ, DALI On / OŸ, DALI PRODUCT VARIANTS 49

IP20/54 IK02 INDOOR DOWNLIGHT Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature DOWNLIGHT V 100 830 / 840, 6 W, IP54 6 W 220-240 V 610 lm 101 lm/W 3.000 K 640 lm 106 lm/W 4.000 K DOWNLIGHT V 150 830 / 840, 9 / 15 W, IP54 15 W 220-240 V 1.750 lm 116 lm/W 3.000 K 1.900 lm 126 lm/W 4.000 K DOWNLIGHT V 200 830 / 840, 15 / 21 W, IP54 21 W 220-240 V 2.360 lm 112 lm/W 3.000 K 2.490 lm 118 lm/W 4.000 K DOWNLIGHT V *S = in stock O = to order 50

Ø 9,5 3,7 0,2 Ø 10,6 0,3-2 min 1,8 Ø 15 3,9 0,2 Ø 16,8 min 1,6 0,3-2 Ø 20 3,9 0,2 Ø 21,4 min 1,6 0,3-2 Product designation Colour Availability* Prod no. EUR DOWNLIGHT V 100 black flat bezel S 1007477 5.00 DOWNLIGHT V 100 white flat bezel S 1007476 5.00 DOWNLIGHT V 100 recessed bezel black S 1007479 5.00 DOWNLIGHT V 100 recessed bezel white S 1007478 5.00 DOWNLIGHT V 150 black flat bezel S 1007481 7.00 DOWNLIGHT V 150 white flat bezel S 1007480 7.00 DOWNLIGHT V 150 recessed bezel black S 1007483 7.00 DOWNLIGHT V 150 recessed bezel white S 1007482 7.00 DOWNLIGHT V 200 black flat bezel S 1007485 10.00 DOWNLIGHT V 200 white flat bezel S 1007484 10.00 DOWNLIGHT V 200 recessed bezel black S 1007487 10.00 DOWNLIGHT V 200 recessed bezel white S 1007486 10.00 CRI UGR Control Emergency lighting Availability* Prod no. EUR 50.000h L70B50 >80 >28 105° - - On / Off S 1007508 45.00 50.000h L70B50 >80 >28 105° - - On / Off S 1007509 53.00 50.000h L70B50 >80 >28 105° - - On / Off S 1007510 60.00 51

INDOOR DOWNLIGHT Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature DOWNLIGHT C 150 8 / 14 / 20 W, 930 20 W 220-240 V 2.250 lm 112 lm/W 3.000 K DOWNLIGHT C 150 8 / 14 / 20 W, 940 20 W 220-240 V 2.400 lm 120 lm/W 4.000 K DOWNLIGHT C 200 8 / 16 / 24 W, 930 24 W 220-240 V 2.850 lm 118 lm/W 3.000 K DOWNLIGHT C 200 8 / 16 / 24 W, 940 24 W 220-240 V 3.100 lm 129 lm/W 4.000 K DOWNLIGHT C dali 150 20 W, 930 20 W 220-240 V 2.250 lm 112 lm/W 3.000 K DOWNLIGHT C DALI 150 20 W, 940 20 W 220-240 V 2.400 lm 120 lm/W 4.000 K DOWNLIGHT C DALI 200 24 W, 930 24 W 220-240 V 2.850 lm 118 lm/W 3.000 K DOWNLIGHT C DALI 200 24 W, 940 24 W 220-240 V 3.100 lm 129 lm/W 4.000 K IP54 IK02 DOWNLIGHT C *S = in stock O = to order 52

min. 3,2 10-25 mm Ø 15,5 0,3 Ø 17,6 8,3 min. 3,2 0,3 9,3 1025 mm Ø 20,5 Ø 22,6 CRI UGR Control Emergency lighting Availability* Prod no. EUR 70.000h L80B10 >90 22 55° - - On / Off S 1008621 89.00 70.000h L80B10 >90 22 55° - - On / Off S 1008622 89.00 70.000h L80B10 >90 22 55° - - On / Off S 1008623 109.00 70.000h L80B10 >90 22 55° - - On / Off S 1008624 109.00 70.000h L80B10 >90 22 55° - - DALI S 1008625 129.00 70.000h L80B10 >90 22 55° - - DALI S 1008626 129.00 70.000h L80B10 >90 22 55° - - DALI S 1008627 149.00 70.000h L80B10 >90 22 55° - - DALI S 1008628 149.00 53

IP54 IK02 INDOOR DOWNLIGHT DOWNLIGHT P Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature DOWNLIGHT P 12 HG 840 60 ML DALI WH 8 W 220-240 V 1.200 lm 150 lm/W 4.000 K DOWNLIGHT P 12 HG 840 60 ML WH 8 W 220-240 V 1.200 lm 150 lm/W 4.000 K DOWNLIGHT P 12 WM 840 60 ML WH 8 W 220-240 V 1.200 lm 150 lm/W 4.000 K DOWNLIGHT P 12 WM 840 60 ML DALI WH 8 W 220-240 V 1.200 lm 150 lm/W 4.000 K DOWNLIGHT P 18 HG 840 60 ML DALI WH 15 W 220-240 V 1.800 lm 150 lm/W 4.000 K DOWNLIGHT P 18 HG 840 60 ML WH 15 W 220-240 V 1.800 lm 150 lm/W 4.000 K DOWNLIGHT P 18 WM 840 60 ML WH 15 W 220-240 V 1.800 lm 150 lm/W 4.000 K DOWNLIGHT P 18 WM 840 60 ML DALI WH 15 W 220-240 V 1.800 lm 150 lm/W 4.000 K DOWNLIGHT P 30 HG 840 60 ML WH 21 W 220-240 V 3.060 lm 170 lm/W 4.000 K DOWNLIGHT P 30 HG 840 60 ML DALI WH 21 W 220-240 V 3.060 lm 170 lm/W 4.000 K DOWNLIGHT P 30 WM 840 60 ML DALI WH 21 W 220-240 V 3.060 lm 170 lm/W 4.000 K DOWNLIGHT P 30 WM 840 60 ML WH 21 W 220-240 V 3.060 lm 170 lm/W 4.000 K DOWNLIGHT P 40 HG 840 60 ML DALI WH 29 W 220-240 V 4.080 lm 170 lm/W 4.000 K DOWNLIGHT P 40 WM 840 60 ML DALI WH 29 W 220-240 V 4.080 lm 170 lm/W 4.000 K DOWNLIGHT P 40 HG 840 60 ML WH 29 W 220-240 V 4.080 lm 170 lm/W 4.000 K DOWNLIGHT P 40 WM 840 60 ML WH 29 W 220-240 V 4.080 lm 170 lm/W 4.000 K *S = in stock (november 2025 O = to order 54

84 49,5 58,5 Ø 68 Ø 100 115 60 69 165 73 82 Ø 150 230 85,5 94,5 Ø 200 CRI UGR Control Emergency lighting Availability* Prod no. EUR 80.000h L80B10 >80 21 60° - - DALI S 1010755 120.00 80.000h L80B10 >80 21 60° - - On / Off S 1010756 80.00 80.000h L80B10 >80 21 60° - - On / Off S 1010757 80.00 80.000h L80B10 >80 21 60° - - DALI S 1010758 120.00 80.000h L80B10 >80 21 60° - - DALI S 1010759 150.00 80.000h L80B10 >80 21 60° - - On / Off S 1010760 120.00 80.000h L80B10 >80 21 60° - - On / Off S 1010761 120.00 80.000h L80B10 >80 21 60° - - DALI S 1010762 150.00 80.000h L80B10 >80 23 60° - - On / Off S 1010763 150.00 80.000h L80B10 >80 23 60° - - DALI S 1010764 180.00 80.000h L80B10 >80 23 60° - - DALI S 1010765 180.00 80.000h L80B10 >80 23 60° - - On / Off S 1010766 150.00 80.000h L80B10 >80 23 60° - - DALI S 1010767 230.00 80.000h L80B10 >80 23 60° - - DALI S 1010768 230.00 80.000h L80B10 >80 23 60° - - On / Off S 1010769 200.00 80.000h L80B10 >80 23 60° - - On / Off S 1010770 200.00 55

UNIVERSAL DOWNLIGHT When purchasing a UNIVERSAL DOWNLIGHT multipack, the bezels are not included as standard. COMBINE Bezel in black or white, fixed or swivelling, round or square

UNIVERSAL DOWNLIGHT NEW: Lockable springs PRODUCT ADVANTAGES Fixed (IP65) and swivelling (IP20) downlight in one product Flexibly adjustable thanks to Multi-Colour 2,700 K / 3,000 K / 4,000 K / 6,500 K and Multi-Lumen 5W / 7W EASY TO INSTALL thanks to the quick-release connection box and lockable springs Airtight when used with IP65 rigid covers Can be installed directly into the insulation or covered with insulation. Tested for use in fire-retardant rated suspended ceilings BSE 476-2 EN 1365-2 57

88 x 35 88 x 88 x 35 IP20 IK02 INDOOR UNIVERSAL DOWNLIGHT L x W x H (mm): Ø x L (mm): Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature UNIVERSAL DOWNLIGHT PHASE Multipack, 12 pieces 7 W 220-240 V 670 lm 95 lm/W 2.700 K 680 lm 97 lm/W 3.000 K 690 lm 98 lm/W 4.000 K 680 lm 97 lm/W 6.500 K Product designation Colour Availability* Prod no. EUR UNIVERSAL DOWNLIGHT Bezel For downlight IP20, pivoting, square, black S 1007184 4.00 UNIVERSAL DOWNLIGHT Bezel For downlight IP20, pivoting, square, white S 1007185 4.00 UNIVERSAL DOWNLIGHT Bezel For downlight IP20, pivoting, round, black S 1007091 3.00 UNIVERSAL DOWNLIGHT Bezel For downlight IP20, pivoting, round, white S 1007092 3.00 UNIVERSAL DOWNLIGHT Bezel For downlight IP65, square, black S 1008096 3.00 UNIVERSAL DOWNLIGHT Bezel For downlight IP65, square, white S 1008095 3.00 UNIVERSAL DOWNLIGHT Bezel For downlight IP65, round, black S 1008067 3.00 UNIVERSAL DOWNLIGHT Bezel For downlight IP65, round, white S 1008068 3.00 UNIVERSAL DOWNLIGHT *S = in stock O = to order 58

Ø 68 - 75 54 3 Ø 85 10-30 CRI UGR Control Emergency lighting Availability* Prod no. EUR 50.000h L80B50 >90 - 38° - 30° Phase S 1008066 289.00 59

3.000 K or 4.000 K

SURFACE PRODUCT ADVANTAGES Splash-proof and dust-proof light IP44 for use in the bathroom, stairwell or cellar Flexibly adjustable thanks to Multi-Colour and Multi-Lumen EASY TO INSTALL thanks to removable cover Sensor variant for highly energy-e˜cient use Variant with sensor available 61

IP44 IK02 INDOOR SURFACE Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature SURFACE V 390 390, 830 / 840, 10 / 15 / 22 W, IP44 20 W 220-240 V 1.850 lm 93 lm/W 3.000 K 2.000 lm 100 lm/W 4.000 K SURFACE V 390 390, 11 / 16 / 23 W, 830 / 840, Sensor 20 W 220-240 V 1.850 lm 93 lm/W 3.000 K 2.000 lm 100 lm/W 4.000 K SURFACE V *S = in stock O = to order 62

CRI UGR Control Emergency lighting Availability* Prod no. EUR 50.000h L80B10 >80 - 120° - - On / Off S 1007516 50.00 50.000h L80B10 >80 - 120° - - On / Off S 1007517 65.00 63

Integrated PIR sensor for motion-dependent light control, with adjustable range and run-on time. Emergency lighting module with automated self-test function in accordance with EN 62034 – up to 3 hours of autonomy in the event of a power failure.

BATTEN PRODUCT ADVANTAGES Replacement product for conventional T5/T8 lights Service life up to 100,000 hours EASY TO INSTALL thanks to through-wiring as standard Flexibly adjustable thanks to Multi-Lumen and Multi-Colour All DALI variants support DC operation Halogen-free Service life 100,000 hours 65

IP20 IK04 INDOOR BATTEN BATTEN P Product designation Colour Max. Total wattage Mains voltage Max. Luminous flux Efficiency Colour temperature BATTEN P 600 28, 830 / 840 / 850, WH 20 W 220-240 V 2.600 lm 130 lm/w 3.000 K 2.800 lm 140 lm/w 4.000 K 2.800 lm 140 lm/w 5.000 K BATTEN P 600 52, 830 / 840 / 850, WH 35 W 220-240 V 5.000 lm 145 lm/w 3.000 K 5.000 lm 145 lm/w 4.000 K 5.200 lm 150 lm/w 5.000 K BATTEN P 600 52, 830 / 840 / 850, WH, EM, 3H 35 W 220-240 V 5.000 lm 145 lm/w 3.000 K 5.000 lm 145 lm/w 4.000 K 5.200 lm 150 lm/w 5.000 K BATTEN P 1200 52, 830 / 840 / 850, WH, PIR 35 W 220-240 V 5.000 lm 145 lm/w 3.000 K 5.000 lm 145 lm/w 4.000 K 5.200 lm 150 lm/w 5.000 K BATTEN P 1200 52, 830 / 840 / 850, WH, DALI 35 W 220-240 V 5.000 lm 145 lm/w 3.000 K 5.000 lm 145 lm/w 4.000 K 5.200 lm 150 lm/w 5.000 K BATTEN P 1200 52, 830 / 840 / 850, WH, DALI, EM, 3H 35 W 220-240 V 5.000 lm 145 lm/w 3.000 K 5.000 lm 145 lm/w 4.000 K 5.200 lm 150 lm/w 5.000 K *S = in stock O = to order 66

1040 56 65 1200 56 65 517 600 CRI UGR Control Emergency lighting Availability* Prod no. EUR 100.000h L80B10 >80 28,8 - - - On / Off O 1009251 50.00 100.000h L80B10 >80 28,8 - - - On / Off O 1009252 70.00 100.000h L80B10 >80 28,8 - - - On / Off O 1009253 130.00 100.000h L80B10 >80 28,8 - - - On / Off O 1009254 100.00 100.000h L80B10 >80 28,8 - - - DALI O 1009258 120.00 100.000h L80B10 >80 28,8 - - - DALI O 1009259 200.00 Product designation Colour Availability* Prod no. EUR BATTEN P SCK 2000 Safety cable 2000mm O 1009262 10.00 L (mm): 2000 67
